| SENSOR TYPE | Magnetic proximity switch |
|---|---|
| HOUSING TYPE | Cylindrical-Threaded |
| HOUSING MATERIAL | (Metal)Nickel Plated Brass |
| HOUSING SIZE | M18X1 |
| SENSING SURFACE MATERIAL | polyamide |
| HEAD COLOR | RED |
| NUMBER OF WIRES | 3 |
| OUTPUT STAGE | REED RELAY |
| OUTPUT FUNCTION | Normally close |
| RATED SWITCHING DISTANCE | 10 mm |
| MOUNTING TYPE | flush(shielded) |
| OPERATING VOLTAGE | 10…30VDC |
| RATED OUTPUT CURRENT | 250 mA |
| TEMPERATURE RANGE | -20…+60 °C |
| MAX SWITCHING FEREQUENCY | 50 Hz |
| OPERATING INDICATOR | RED LED |
| SENSITIVITY ADJUST | No |
| MAX OUTPUT DROP VOLTAGE | 2 v |
| MAX NOLOAD CURTRENT | 0 mA |
| INFLUENCE PROTECTION | IEC IP66(DIN 40050) |
| ELECTRICAL CONNECTION | PVC CABLE,3X0.25,1.5m |
| REVERS VOLTAGE PROTECTION | protected |
| PICK VOLTAGE PROTECTION | protected |
| SHORT CIRCUIT PROTECTION | NOT protected |
Category: Three-Wire Magnetic Sensors
| SENSOR TYPE | Magnetic proximity switch |
|---|---|
| HOUSING TYPE | Cylindrical-Threaded |
| HOUSING MATERIAL | (Metal)Nickel Plated Brass |
| HOUSING SIZE | M18X1 |
| SENSING SURFACE MATERIAL | polyamide |
| HEAD COLOR | RED |
| NUMBER OF WIRES | 3 |
| OUTPUT STAGE | REED RELAY |
| OUTPUT FUNCTION | Normally close |
| RATED SWITCHING DISTANCE | 10 mm |
| MOUNTING TYPE | flush(shielded) |
| OPERATING VOLTAGE | 10…30VDC |
| RATED OUTPUT CURRENT | 250 mA |
| TEMPERATURE RANGE | -20…+60 °C |
| MAX SWITCHING FEREQUENCY | 50 Hz |
| OPERATING INDICATOR | RED LED |
| SENSITIVITY ADJUST | No |
| MAX OUTPUT DROP VOLTAGE | 2 v |
| MAX NOLOAD CURTRENT | 0 mA |
| INFLUENCE PROTECTION | IEC IP66(DIN 40050) |
| ELECTRICAL CONNECTION | PVC CABLE,3X0.25,1.5m |
| REVERS VOLTAGE PROTECTION | protected |
| PICK VOLTAGE PROTECTION | protected |
| SHORT CIRCUIT PROTECTION | NOT protected |
